| CHARACTERISTICS |
| Operating Speed |
1mm-2m/sec |
| Operating Frequency |
Mechanical: 120 operations/min. |
| Electrical: 30 operations/min. |
| Contact Resistance |
15mΩ max. (initial value) |
| Insulation Resistance |
100mΩ min. (below 500VDC) |
| Dielectric Strength |
50/60Hz for 1 Minute between terminal of the same polarity |
| 50/60Hz for 1 minute between current carrying and non-current carrying metal parts |
| 1500VAC, 50/60Hz for 1 minute between each terminal and ground |
| Vibration |
10-55Hz,1.5mm double amplitude |
| Shock |
Mechanical durable: 1,000m/sec2 (about 100G'S) |
| Electrical: 300m/sec2 (about 30G'S) |
| Ambient temperature |
-10℃ to 85℃(with no icing) |
| Humidity |
<95%RH |
| Life |
Mechanical: 10 Million Operations Above |
| Electrical: 500,000 Operations Above |
| Degree of protection |
IP65 (IEC Standard) |
